Product Overview
The EnVision RDL-Line (LED-DL-SQ-4-9W-5CCT-UNV-0/10V) is a commercial-grade led downlight delivering 9w, 765 lm, Selectable 27/30/35/40/50K. Engineered for reliable performance and easy specification.
Key Features
- Wattage: 9w
- Lumens: 765 lm
- Color Temperature: Selectable 27/30/35/40/50K
- Voltage: 120-277V
- Dimming: 0-10V
- CRI: >90
- IP Rating: Wet Location
- Beam: 100°
- Finish: White
- Listing/Warranty: ETL/ ES/ JA8/ 5 Years
Technical Specifications
| Brand | EnVision |
|---|---|
| Model / SKU | LED-DL-SQ-4-9W-5CCT-UNV-0/10V |
| Type | LED Downlight |
| Wattage | 9w |
| Lumens | 765 lm |
| Color Temperature | Selectable 27/30/35/40/50K |
| Voltage | 120-277V |
| Dimming | 0-10V |
| CRI | >90 |
| IP Rating | Wet Location |
| Beam Angle | 100° |
| Finish | White |
| Size | 4″ |
| Box Qty | 60 |
| Certification / Warranty | ETL/ ES/ JA8/ 5 Years |
| UPC | 810143716320 |
| ES/DLC ID | PENDING 2/2025 |
Lumera Electric supplies genuine EnVision commercial LED lighting with full manufacturer specifications and competitive project pricing.
