Product Overview
Engineered for manufacturing floors, the EnVision LED-RHBL-3P120-TRI-EX39 high bay provides up to 19,200 lumens with selectable 120/100/80w output across a 120-277V range, pairing verified performance with fast field specification.
Key Features
- Selectable power: 120/100/80w set at install, one SKU covering multiple loads
- Output: up to 19,200 lumens matching the selected wattage
- Field-selectable color: 3000K-5000K (3 CCT) chosen on the fixture, no re-order
- Beam angle: 100° for even coverage
- Color rendering: CRI>80
- Rating: IP64 Damp Location
- Finish: Clear
- Compliance: UL/DLC Listed
- Packaged 4 per box
Technical Specifications
| Brand | EnVision |
|---|---|
| Wattage | 120/100/80w |
| Lumens | 19,200/16,000/12,800 |
| Color Temperature | 3000K-5000K (3 CCT) |
| Voltage | 120-277V |
| Beam Angle | 100° |
| CRI | >80 |
| IP Rating | IP64 Damp Location |
| Finish | Clear |
| Certification | UL/DLC |
| Box Quantity | 4 |
| UPC | 810143715392 |
Applications
Suited to manufacturing floors, gymnasiums and big-box retail, and high-ceiling industrial bays.
Compatibility & Installation Notes
Confirm mounting height and required foot-candles for your ceiling before ordering. Set the wattage and CCT switches before final mounting. Verify the location suits a damp-rated fixture. DLC listing supports utility rebates—verify your program’s current QPL.
Choose the LED-RHBL-3P120-TRI-EX39 when a project needs dependable output with minimal spec overhead.
