The FQ Recessed series offers a complete line of high performance LED luminaires that provide outstanding functionality and quality. The series features superlative glare control with 30° shielding, 35° vertical tilting and 360° horizontal rotation, and uniform floor-to-ceiling wall washing. Multiple power level options and a full line of round and square, trimmed and trimless luminaires offer versatile solutions for various lighting applications. Easy to order, install, and service.
Features
- Housing required – sold separately
- Finish: Black, Dark Bronze, Haze, White
- Construction: Durable Two-piece die-cast Aluminum trim with Aluminum heat sink
- Wattage: 15W, 21W, 25W (Depends on Housing selection)
- Voltage: 120-277V
- Color Temperature: 4000K
- Delivered Lumens: 2165lm
- CRI: 90
- ELV Dimming: 100-1%
- 0-10V Dimming: 100-1%
- TRIAC Dimming: 100-1%
- Rated Life: 50,000 Hours
- Light engine mounted on trim with springs for easy replacement
- 30° shielding angle design for great visual comfort
- Field changeable beam angle with reflectors provided
- Accepts one Lens or glare control accessory
Compatible Housings (Sold Separately):
- New Construction – R2FRNL-1 , R2FRNL-2 , R2FRNL-3
- Remodel – R2FRRL-1 , R2FRRL-2 , R2FRRL-3
Dimensions
- Aperture Size: 2″
- Width: 2.75″
- Height: 5“
- Ceiling Cutout: 3.5″ Dia.
- Ceiling Thickness: 0.5″ – 1″
Lamping
- 15W, 21W, 25W LED (Depends on Housing selection, Not Included)
Documents
- Spec Sheet
- Instruction Sheet
